FASTUP TENT manufactures warehouse tents for rental and resell, whether you want a temporary building or a permanent building, FASTUP TENT can provide you with the ideal solution. Our warehouse tents are convenient for enterprises to provide a flexible space for storage, reducing the cost of warehouse places rental.
Warehouse Tent does not require a permanent foundation, which can be set up in any kind of ground ---- asphalt, concrete or grassland. In the aspects of the economics and flexibility, aluminum tent is far better than traditional steel tent. Tent does not need to have a building permit to start building. For little basic conditions required, so the cost is low, the maintenance is simple. The modular design warehouse tents and storage tents are integrated to provide a good foundation, which can be customized as per your needs for industrial applications.
Warehouse tent all sizedimension
|
Fastup Tent |
Width |
Bay Distance (m) |
Side height (m) |
Ridge height (m) |
Main frame profile |
Roof Pitch |
Wind Load (km/h) |
Snow Load (Kn/m2) |
|
SPT3/2300 |
3m |
3m |
2.5m |
3.1m |
100X48mm |
22° |
80 |
0.3 |
|
SPT4/2300 |
4m |
3m |
2.5m |
3.3m |
100X48mm |
22° |
80 |
0.3 |
|
SPT5/2500 |
5m |
3m |
2.5m |
3.5m |
100X48mm |
22° |
80 |
0.3 |
|
SPT6/2500 |
6m |
3m |
2.5m |
3.7m |
100X48mm |
22° |
80 |
0.3 |
|
SPT8/2500 |
8m |
3m |
2.5m |
4.1m |
100X48mm |
22° |
80 |
0.3 |
|
SPT9/2500 |
9m |
3m |
2.5m |
4.3m |
100X48mm |
22° |
80 |
0.3 |
|
SPT10/2500 |
10m |
5m |
3m |
4.65m |
122X68mm |
22° |
100 |
0.3 |
|
MPT12/2500 |
12m |
5m |
3m |
5m |
122X68mm |
22° |
100 |
0.3 |
|
MPT15/3000 |
15m |
5m |
3m |
5.35m |
150X110mm |
18° |
100 |
0.3 |
|
MPT18/3000 |
18m |
5m |
3m |
5.8m |
150X110mm |
18° |
100 |
0.3 |
|
LPT20/4000 |
20m |
5m |
4m |
7.2m |
204X112mm |
18° |
110 |
0.3 |
|
LPT22/4000 |
22m |
5m |
4m |
7.45m |
204X112mm |
18° |
100 |
0.3 |
|
LPT25/4000 |
25m |
5m |
4m |
7.95m |
204X112mm |
18° |
100 |
0.3 |
|
LPT30/4000 |
30m |
5m |
4m |
8.92m |
300X120mm |
18° |
100 |
0.3 |
|
LPT40/4000 |
40m |
5m |
4m |
10.54m |
300X120mm |
18° |
100 |
0.3 |
|
LPT50/4000 |
50m |
5m |
4m |
12.17m |
350X120mm |
18° |
120 |
0.3 |
|
LPT60/4000 |
60m |
5m |
4m |
13.94m |
420X120mm |
18° |
100 |
0.3 |
Material and Quality
|
FRAME |
Hard pressed anodized aluminum alloy 6061/T6 |
|
ROOF COVER |
850g/sqm block-out Double PVC coated polyester, Fire retardant, Water Proof |
|
SIDEWA |
650g/sqm or 850g/sqm PVC; Glass Pannel sidwall, ABS sidewall, Sandwich Wall |
|
CONNECTION |
Hot Dip Gavanized Steel Connector, Aluminum roof connection |
Structure details
