Guangzhou Fastup Tent Manufacturing Co., Ltd.

Cheap Price Arcum Tennis Tent In Kuwait Al Ahmadi Hawally Al Jahra Mahboula

Cheap Price Arcum Tennis Tent In Kuwait Al Ahmadi Hawally Al Jahra Mahboula

Facing the challenges of Kuwait's 50℃ high temperature and strong sandstorms! FUSTUP TENT innovatively developed arc-top tennis tents, with aviation-grade aluminum alloy frames and double-layer anti-UV+PVC composite membrane materials as the core, resistant to strong winds and blocking 98% of ultraviolet rays. The anti-sand coating on the surface of the membrane effectively reduces sand and dust adhesion and maintains light transmittance for a long time.

‌FUSTUP TENT's large arc-top tennis tent has a column-free dome structure to meet the space requirements of professional competitions; the top intelligent partition design takes into account natural ventilation and sunshade, and the light-transmitting film introduces soft light during the day, and is matched with a customized LED lighting system at night to seamlessly switch between training and competition modes. Modular components support quick disassembly and assembly, and the main structure is easy to build to meet temporary or permanent venue requirements.

All size dimension

Fastup Tent Item No.	Width (m)	Bay Distance (m)	Side height (m)	Ridge height (m)	Main frame profile (mm)	Wind Load (km/h)	Snow Load (Kn/m²)
DOM5/2500	5m	3m	2.5m	3.08m	8248mm	100	0.3
DOM10/2500	10m	3m	2.5m	4.03m	100X48mm	100	0.3
DOM15/3000	15m	5m	3m	4.9m	166X88mm	100	0.3
ARC25/4000	25m	5m	4m	4m	204X112mm	100	0.3
ARC30/4000	30m	5m	4m	4m	250X111mm	100	0.3
ARC35/4000	35m	5m	4m	4m	256X113mm	100	0.3

Material Quality

FRAME	Hard pressed anodized aluminum alloy 6061/T6
ROOF COVER	850g/sqm block-out Double PVC coated polyester, Fire retardant, Water Proof
SIDEWA	650g/sqm or 850g/sqm PVC; Glass Pannel sidwall, ABS sidewall, Sandwich Wall
CONNECTION	Hot Dip Gavanized Steel Connector, Aluminum roof connection

Structure details
