Makers High Peak Gazebo Mecca Hajj Tent

Makers High Peak Gazebo Mecca Hajj Tent
The Hajj is one of the five pillars of Islam and the world’s largest pilgrimage. Every able-bodied Muslim is required to make this pilgrimage at least once in their lifetime. The Hajj unfolds in Mecca and areas around it.
FASTUP also exported Hajj tent to Mecca before. The high peak pagoda design makes the rainwater falling down smoothly. And the square aluminum structure makes the whole tent more durable, the max. Allowed wind speed is 80km/h.

Mecca Hajj tent all size dimension

Fastup Tent Item No.	Dimension	Side height (m)	Peak height (m)	Main frame profile (mm)	Wind Load (km/h)	Snow Load (Kn/m²)
SPD3/2500	3m x 3m	2.5m	4.2m	65X65mm	80	0.4
SPD4/2500	4mx 4m	2.5m	4.8m	65X65mm	80	0.4
SPD5/2500	5mx 5m	2.5m	5.2m	65X65mm	80	0.4
SPD6/2500	6m x6m	2.5m	5.8m	65X65mm	80	0.4
SPD8/2500	6m x 6m	2.5m	5.4m	65X65mm	100	0.3
SPD10/2500	10m x10m	2.5m	6.4m	122X68mm	100	0.3
SPD15/2500	15m x15m	3m	8.1m	122X68mm	100	0.3

Material and Quality

FRAME	Hard pressed anodized aluminum alloy 6061/T6
ROOF COVER	850g/sqm block-out Double PVC coated polyester, Fire retardant, Water Proof
SIDEWA	650g/sqm or 850g/sqm PVC; Glass Pannel sidwall, ABS sidewall, Sandwich Wall
CONNECTION	Hot Dip Gavanized Steel Connector, Aluminum roof connection
