Coronavirus Testing Tent

Coronavirus Testing Tent

FASTUP professional relief tents widely purposed for very emergency rescue of such as corona virus, military, floods, earthquakes, and disaster,civil affairs, the Red Cross etc. Using high reinforced aluminum alloy, the frame material is very strong and anti-rust, and can be easily assembled and disassembled according to the requirements. In addition, Safety of the rescue site could be greatly improved by our relief tents which made of flame retardant materials (block-out PVC coated fabric). Sizes from clear span 3m-60m are available which are not only easily transported but also for large accommodations.

Medical tents all sizes

Fastup Tent Item No.	Width (m)	Truss-Distance(m)	Leg height (m)	Ridge height (m)	Truss profile size(m)	Wind load (km/h)	Snow load (KN/m2)
CP6-6/2600	6m	3m	2.6m	3.6m	120x68mm	100	0.3
CP6-9/2600	9m	3m	2.6m	4.1m	120x68mm	100	0.3
CP6-12/2600	12m	5m	2.6m	4.6m	120x68mm	100k	0.4
AP3-20/4000	20m	5m	4m/5.4m	7.09m/8.49m	200x120mm	100	0.4
AP2-30/4000	30m	5m	4m/5.4m	8.87m/10.27m	250x120mm	100	0.4
Ap1-40/4000	40m	5m	4m/5.4m	10.54m/11.94m	300x120mm	100	0.4
Ap10-50/4000	50m	5m	4m/5.4m	12.32m/13.72m	420x120mm	100	0.4

Material and Quality

FRAME	Hard pressed anodized aluminum alloy 6061/T6
ROOF COVER	850g/sqm block-out Double PVC coated polyester, Fire retardant, Water Proof
SIDEWA	650g/sqm or 850g/sqm PVC; Glass Pannel sidwall, ABS sidewall, Sandwich Wall
CONNECTION	Hot Dip Gavanized Steel Connector, Aluminum roof connection

Structure details
